Description
Product description
Resistance rate (Ω×mm) ：＞1015
Dielectric strength (KV×mm)：30
Comparative tracking Index (CTIV)：350
Long working temperature (℃)：100
Lowest Static Working Temperature (℃)：-50
| ITEM NO. | STK-25 | STK-35 | STK-70 | STK-6S | |||||
| Order No. | 06076 | 06006 | 06042 | 06011 | |||||
| Dimentions | |||||||||
| Width x Length x Height | (mm) | 50.5/12/53.5 | 58.5/18/62 | 71/20/76 | 66/8/48.5 | ||||
| Nominal screw diameter | (mm) | M6 | M6 | M6 | M3.5 | ||||
| Torque | (Nm) | 2.0-2.4 | 2.5-5.0 | 0.8-1.6 | |||||
| Stripping Length | (mm) | 20 | 20 | 22 | 12 | ||||
| Rated Data | |||||||||
| Voltage Rating/ Current | (V) / (A) | 800V / 101A | 800V / 125A | 800V / 192A | 800V / 41A | ||||
| Power-frequency withstand voltage | 2.5KV | 2.5KV | 3.0KV | 2.5KV | |||||
| Wire section | (m㎡) | 35 | 35 | 70 | 6 | ||||
| Connecting capacity | |||||||||
| Single wire | (m㎡) | 4-25 | 6-35 | 10-70 | 0.5-10 | ||||
| Multistrand wire | (m㎡) | 4-25 | 10-35 | 10-70 | 1.5-10 | ||||
| Multistrand wire with termina | (m㎡) | 4-25 | 10-35 | 10-70 | 0.5-6 | ||||
